Hot Tub

SPECIFICATIONS

INFO

COLORS

OPTIONS

DOCUMENTS

REVIEWS

#	SPECIFICATION	VALUE
1	Seating Capacity	11
2	Shell Color	Sterling Silver
3	Dimensions (W x L x H)	93" x 151" x 51"
4	Dry Weight - Lbs. (Kilograms)	1,750 (794 kg)
5	Filled Weight - Lbs. (Kilograms)	15,028 (6,817 kg)
6	Water Capacity - Gal. (Liters)	1,600 (6,056 L)
7	Eliminator High Performance™ Pump	2 x 6.0 BHP
8	Operating Voltage	240V
9	Stainless Steel Jets: Exclusive Candy Cane Jets	23
10	Swim Spa Jet System: II and V	2 Exercise Jet System 2 Rip Jets
11	Stainless Steel Exercise Bar	27"
12	Floor Mounted Swim Lane Marker	Yes
13	Fitness Anchors	Yes
14	Tether Anchor	Yes
15	Textured Pillows	Y-Pillow
16	Gate Valve(s)	Yes
17	Twin Pure Silk™ System	Yes
18	Bio-Clean Filter™ with TeleWeir	100 Sq. Ft. (2 x 50 Sq. Ft.)
19	LED Spa Lighting	Multi Colored LED 1 x 5"
20	Whisper Power Unit™ Equipment with Full Color LCD Touch Display	BP501G1 Cal Spas TP500
21	Thermo-Shield™ Insulation Side Panels and Thermo-Layer Floor with ABS Liner	Yes
22	WhisperHot™ Heating System	5.5 kW Titanium Heater
23	Pressure Treated Cabinet Frame	Yes
24	Cabinet Panel with Cal Spas Premium Badge: Smoke & Mist	Cal Preferred™ Horizontal
25	Cabinet Accessible Drain Valve	Yes
26	Spa Cover: Cal Armor™ (Weather Shield) Colors: Gray, Dark Brown, Black	5" - 3" Cal Armor™
27	Warranty (Structural)	10 Years
28	Warranty (Finish)	7 Years
29	Warranty (Parts)	5 Years
30	Warranty (Labor)	5 Years
31	Warranty (Cabinet)	5 Years

SHELL

ACRYLIC COLORS

Hot Tubs, Spas, Portable Spas, Swim Spas for Sale Hot Tubs, Spas, Portable Spas, Swim Spas for Sale Sterling Silver

CABINET

STYLE COLOR CHOICES

Smoke

Mist

COVER

COVER COLORS

Black

Dark Brown

Grey

Cal Salt Filtration

Cal Salt Filtration System (w/ Plastic Jets)

Pure Cure UV Purification System

Cal Connect RF Module

RF allows faster transfer of heavier data-sets to and from your hot tub.

Freedom™ Sound System

Freedom™ Sound System Bluetooth, Powered Subwoofer and (4) Speakers
2 x 3" Black Speakers
2 x 6" White Speakers

Thermo-Guard™ Full Foam Insulation

*This Option will Replace Thermo-Shield

WRITE A REVIEW

Hot Tub CAL SALT

Cal Salt™ Filtration Sanitation System produces a pure form of chlorine by electrolysis of salt (NaCl) providing pure sanitized spa water. Once salt in the water is converted to chlorine, bacteria is killed and the chlorine converts back to salt, the process repeats. Importantly, the salt concentration used is very low (less than that in a human tear).

CONTROL PANEL

Easily located at the front of the spa, giving you more control over the sanitation of your spa.

CELL & HOLDER

Installed in the filter area to maximize water flow of the solution throughout the plumbing and out the jets of your spa.

CAL SALT VIDEO

See Cal Salt™ Filtration System at work.

Hot Tub HYDRO-MASSAGE THERAPY BENEFITS

There are many benefits to improving your mind and body with each spa manufactured. Customize your Hydro-Massage therapy to meet your goal to a healthier better you.

SEATS

Seating

Enjoy lounge or bench style seating; keep an eye out for the cool off seat after your exercise.

*Swim Spa seating varies by model.

JETS

Exclusive Stainless Steel Candy Cane Jets

These jets are strategically placed to hit exact pressure points, which will allow your muscles to decompress. Jets are adjustable at your convenience.

Hot Tub ULTIMATE PERFORMANCE

Cal Spas prides itself on 100% custom built American-made Spas. We are dedicated to building the most reliable, durable and functional spa in the industry.

PUMPS

Eliminator High Performance™ Pump

Cal Spas builds the most reliable motors in the industry. With less moving parts, these motors feature two independent winding speeds and a reverse-flow cooling system. Our pumps are Built to last a lifetime!

HEATER

Whisper Hot™ 5.5 kW Titanium Heater

Titanium Element in calcified Tube Titanium has become the solution to hot tub heater longevity, and has long been the best defense against chemical & mineral abuse.

CONTROLS

Cal Spas Touch2

A modern and intuitive 4in full color LCD touch display designed to easily switch between settings. Including in-depth features, vibrant colors, user feedback and response. Set your spa to your liking with an easy-to-read menu that will leave your spa functioning seamlessly.

HYDRO-PRO

Hydro-Pro Swim-Mill + Resistance I™

Endlessly walk, jog or swim at BEGINNER levels of resistance.

*Resistance Jets vary by model.

Hot Tub PURITY

It is necessary that the water in your spa stays purified, and with our filtration system, we make it easy for you.

OZONE

Twin Pure Silk™ System

Using Dual Ozonators with Mazzei Injectors Mixing Chambers, it kills microorganisms and prevents them from reproducing. No chemicals are added to the water, and won't interfere with the oxidation process.

BIO-FILTER

100 Sq. Ft. Bio-Clean™ with TeleWeir Gate

A special bacteria-fighting agent is molded into the fabric of the filter. This prevents harmful microbes and bacteria from reproducing. A TeleWeir Gate prevents debris from re-entering into your water system.

Hot Tub EFFICIENCY INSULATION

Our insulation is the best on the market. We have it down to a science for you to keep your spa protected and the heat locked in and ready to use at any time!

THERMO-SHIELD

Thermo-Shield™ Side Panel

Our cabinet walls contain premium insulation that is completely recyclable producing less waste than traditional urethane foam. Additionally, the insulation does not block passage to the spa allowing for the highest R rating.

FULL FOAM

Full Foam Insulation

By adding full foam into the spa structure, water is preserved so the heat does not release. This will reduce the time that it takes to heat and maintain water temperature.

*Optional Feature

COVER

Hydro-Armor™ Spa Cover

Our spa cover is built with a tapered edge with an integrated downward angle from the center, this prevents precipitation from pooling on the cover preventing mold or mildew. The Hydro-Armor cover is made from 100% marine-grade with a vinyl top, filled and supported by 18-gauge steel C-Channel beams.

COVER UPGRADE

Cal Armor™

Same durability and grade as our existing covers but 1/3 LIGHTER and 3X STRONGER!

*This feature is limited only to certain models.

CABINET

Cal Preferred™ Cabinet Panels

Each cabinet is designed to provide maximum support for every spa. Match your favorite shell color with eye-catching panels available in select colors.

Hot Tub STRENGTH STARTS UNDERNEATH

With a strong foundation our spas are built to last.

FIBER STEEL

Fibersteel™ Construction

How a Spa shell is built determines everything from longevity to durability to withstand every outdoor element. Cal Spas Patented 5-layer laminate design incorporating reinforced steel and wood is the strongest in the industry. Cal Spas Fiber steelTM process has proven to lead the industry in shell design, efficiency and performance.

FRAME

Pressure Treated Wood Cabinet Frame

Our cabinet frames are treated to resist rot, corrosion and insects. Constructed using 1" galvanized steel fasteners, corner gussets, and vertical angle bracings for added beam support.

PLUMBING

VGB Approved Vacuum Break Intake System

This safety break feature automatically reduces pump suction in the event of an obstruction or intake blockage.

FOAM

Hydro Steel Foam

This high-density foam is added to support the plumbing underneath so nothing gets out of place

Hot Tub LIFE PLEASURES

To be in a spa feels great, add the extra, then it becomes perfect!

HYDRO-STREAMERS™

LED Dual HydroStreamers Plus™ with Valve

Up to eight breathtaking LED Hydro-Streamers™ instantly turn any backyard into a beautiful tropical paradise option on selected model.

SOUND SYSTEM

Freedom™ Sound System

Includes Bluetooth, Powered Subwoofer and 2 Speakers. Bluetooth technology lets you control your music through your smart device from anywhere inside, or outside your Cal Spas Hot Tub.
*This feature varies by model.

WI-FI

Wi-Fi Module

Using Wi-Fi allows you to control your spa from anywhere in your home. Turn your spa on and off with ease. Control your filter cycles, the temperature and the pumps. You choose!

*Optional Feature

WI-FI UPGRADE

Cal Connect™ System

Upgrade your Wifi connection to direct RF (Radio Frequency). Your spa will have its own local IP address and can talk to other smart appliances and devices like Alexa and can be controlled and monitored anywhere around the world via the built-in Cal Spas app
*This feature varies by model. Alexa is a registered trademark of Amazon.
